Custom designed and fabricated multi-fuel boilers and heat plants.
Custom designed and fabricated multi-fuel boilers and heat plants.
Our boilers are available with a range of fuel options including biomass, solid fuel, gas, liquid fuel and electricity. Respected for our mechanical and project engineering capabilities, we provide comprehensive design, fabrication, installation, and commissioning services to a broad range of industry sectors.
Contact our sales experts
Free customization of boilers of different specifications
Low operating pressure, low operating cost
Up to 15% less energy usage due to low operation pressure and lacking of moving parts
Up to 90% reduced wafer consumption due to use of filtrate in filfer back washe
Computerized control for one-touch start and auto on/off operation. Stainless steel body, corrosion-resistant and more durable.
| Model | Rated Power (KW) |
Rated Heating Output (KG/H) |
Rated Pressure (MPa) |
Rated Steam Temperature (℃) |
Water Capacity (L) |
Weight (KG) |
Packing Size (CM) |
|---|---|---|---|---|---|---|---|
| LDR0.004-0.4 Semi-auto | 3 | 4 | 0.4 | 150 | 15 | 28 | 54*40*76 |
| LDR0.004-0.4 LDR0.004-0.7 |
3 | 4 | 0.4/0.7 | 150/170 | 15 | 45 | 63*40*83 |
| LDR0.008-0.4 LDR0.008-0.7 |
6 | 8 | 0.4/0.7 | 150/170 | 18 | 60 | 68*41*83 |
| LDR0.012-0.4 LDR0.012-0.7 |
9 | 12 | 0.4/0.7 | 150/170 | 20 | 65 | 73*46*87 |
| LDR0.016-0.4 LDR0.016-0.7 |
12 | 16 | 0.4/0.7 | 150/170 | 20 | 66 | 73*46*87 |
| LDR0.024-0.4 LDR0.024-0.7 |
18 | 24 | 0.4/0.7 | 150/170 | 28 | 75 | 77*51*92 |
| LDR0.032-0.4 LDR0.032-0.7 |
24 | 32 | 0.4/0.7 | 150/170 | 28 | 77 | 78*52*93 |
| LDR0.048-0.4 LDR0.048-0.7 |
36 | 48 | 0.4/0.7 | 150/170 | 28 | 80 | 80*54*93 |
| LDR0.064-0.4 LDR0.064-0.7 |
48 | 64 | 0.4/0.7 | 150/170 | 28 | 93 | 83*58*103 |
| LDR0.096-0.4 LDR0.096-0.7 |
72 | 96 | 0.4/0.7 | 150/170 | 29 | 128 | 83*58*113 |
*The above data are for reference only. For specific information, please refer to the actual product and product manual. Unless otherwise specified, the right to interpret the data involved in this website belongs to DABONN.
*For other model details, please contact us.
